SQX Pressure Switch

The SQ Series pressure switches are available in a wide variety of configurations.



Description

Overview:

The SQ Series pressure switches are available in a wide variety of configurations. The SQ pressure switch utilises an internal diaphragm which is subjected to the process pressure through a connection in the application. A variety of fixed or adjustable ranges, and electrical connections, are available.

Stock Unit Model Number:

  • SQ276-RL1-2U-V-C

1-19 Bar Adj SS 1/4″NPT

Please send us an enquiry should you need a different configuration in the SQX series.

Features:

  • Robust pressure switch even in severe duty applications
  • Choice of body materials; 316SS, zinc plated steel and brass
  • Selectable contact, electrical connection and accessories
  • Adjustable or fixed pressure
  • High quality and cost effective

Applications:

  • Pressure control
  • Safety monitoring of pressure in pipes
  • Pressure control in manufacturing systems and machinery

INDUSTRY

  • HVAC systems
  • Automotive
  • Sprinkler systems
  • Lubrication equipment
  • Industrial compressors
